The XF-88 Safety Guard Foot Switch is a heavy-duty industrial foot switch designed for applications requiring enhanced operator safety and reliable machine control. Featuring a rugged aluminum alloy housing, fully enclosed safety guard cover, and a slow-action switching mechanism, the XF-88 effectively helps prevent accidental activation while ensuring stable control performance. With a 10A switching capacity, IP65 protection rating, and customizable cable lengths, it is an ideal solution for machine tools, stamping equipment, welding systems, hydraulic machinery, automation equipment, and other safety-critical industrial applications.
Material: Aluminum Alloy
Inner Switch: Slow Action Type
Rating Load: 10A / 250VAC
Contact Form: 1NC1NO
Protection Degree: IP65
Cable Length: Custom Length Available
Mechanical Life: ≥1,000,000 Operations
Suitable for machine tools, stamping equipment, welding systems, hydraulic machinery, industrial automation equipment, production lines, packaging machinery, and other safety-critical industrial control applications.
Robust construction and simple design allow convenient installation and maintenance.
Designed for more than 1 million mechanical operations, ensuring dependable long-term performance.
Cable length can be customized according to customer installation requirements.
The safety guard design helps prevent accidental foot contact and unintended machine activation.
Dust-tight and protected against water jets, making it suitable for harsh industrial environments with dust, moisture, and debris.
Built-in slow-action switch ensures smooth and reliable operation with stable switching performance.
High-strength aluminum alloy housing offers excellent impact resistance, wear resistance, and long-term durability in demanding environments.
Rated for 10A at 250VAC, making it suitable for a wide range of industrial machinery and control systems.
Provides one normally closed and one normally open contact, suitable for safety circuits, interlocking systems, and industrial control applications.
Designed with a single pedal structure for simple and reliable machine start-stop or function control.
The large protective guard cover minimizes accidental activation and provides enhanced operator safety during machine operation.
| Product model | XF-88 |
| Contact resistance | 25mΩ(initial value) |
| Insulation resistance | 100mΩ Above DC500V |
| Withstand voltage | ≥2000VAC |
| Mechanical Life | 1,000,000ops above |
| Electrical Life | 100,000ops above |
| Operating temperature | -20~+70°C |
| Operating Humidity | ≤85% |
| Material | Aluminium |
| Inner Switch | Slow Action Type |
| Rating Load | 10A/250VAC |
| Contact Form | 1NC1NO |
| 0utgoing Cable | -- |
| Protection Degree | IP64 |
Compliant with GB national standards, with CCC and CQC certification for domestic sales and bidding compliance.
Comply with CE, RoHS, REACH and EN standards, approved by TÜV & VDE, and support ATEX certification for explosive hazardous areas.
UL, CUL and CSA certified, conforming to North American electrical safety specifications for US and Canada market access.
Adapt to Japanese PSE and Korean KC certification, follow JIS and KS local standards to meet market access regulations of Japan and South Korea.
Custom voltage & current, AC/DC type, zero-cross or random trigger.
Custom mounting, terminals and non-standard dimensions.
Custom heat dissipation, high isolation, potting and anti-corrosion protection.
Overheat/overcurrent protection, anti-interference, delay and soft start optional.
Custom logo, marking, OEM/ODM and personalized solution design.
Regular customization: 3-7 working days
Complex Customization: 7-15 working days
Urgent Sampling: 24-72 hours
2222 US dollars
Conventional products have no minimum order quantity. Customized products can be consulted with customer service
The delivery time usually varies depending on the quantity and model of the order, usually 3-5 days. For specific times, please consult us
